Name: Lantronix EDS 3000PS SECURE SERIAL DEVICE SERVER 16PORT SERIAL 1GBE ENET EDS3016PS1NS
SKU: EDS3016PS1NS
Price: 969.00 USD
Availability: InStock

Description

EDS 3000PS SECURE SERIAL DEVICE SERVER 16PORT SERIAL 1GBE ENET

Features

Ethernet 10Base-T or 100Base-TX (auto sensing and hard-coded, auto crossover)
Interface: Software selectable RJ45 serial ports with customizable baud rate support for non-standard serial speeds
Data Rates: Software selectable standard baud rates from 300 to 230 K Baud
Connectors: 8 or 16 RJ45 serial ports depending upon model
Characters: 7 or 8 data bits
Parity: Odd, even, none
Stop Bits: 1 or 2
Modem Control Signals: CTS, RTS, DTR, DCD
Flow Control: XON/XOFF (software), CTS/RTS (hardware), None

Tech Specs

Basic
Product Type	Device Server
Form Factor	Wall Mountable
Form Factor	Desktop
Brand Name	Lantronix
Network Standard	10/100/1000Base-T
Product Condition	New
Ethernet Technology	Gigabit Ethernet
Number of Network (RJ-45) Ports	1
Product Family	EDS
Media Type Supported	Twisted Pair
Number of Serial Ports	16
General Information
Product Type	Device Server
Manufacturer Part Number	EDS3016PS1NS
Manufacturer Website Address	http://www.lantronix.com
Manufacturer	Lantronix, Inc
Product Model	EDS3016PS
Product Name	EDS EDS3016PS Device Server
Product Series	EDS
Brand Name	Lantronix
Product Condition	New
Interfaces/Ports
Number of Network (RJ-45) Ports	1
Network (RJ-45)	Yes
Number of Serial Ports	16
Media & Performance
Media Type Supported	Twisted Pair
Memory
Standard Memory	512 MB
Miscellaneous
Additional Information	Hardware: CPU: Cortex A9 On-board memory: 8MB Flash 4 Gbit (512 MB) Flash Serial Interface: Software selectable data rates from 300 to 230K Baud Characters: 7 or 8 data bits Parity: Odd, Even, None Stop Bits: 1 or 2 Modem Control Signals: CTS, RTS, DTR, DCD Flow Control: XON/XOFF (software) CTS/RTS (hardware), None Network Interface Protocols: HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP, DHCP, SSHv2 , SSLv3, SNMP v2, Auto IP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, SNTP Security: SSL 3, TLS 1.0, TLS 1.1, TLS 1.2, TLS 1.3s MD5,SHA-1,SHA-2 RSA, DSA and ECDSA Password protection IP address filtering Software: Lantronix Provisioning Manager ComPort Redirector™ Secure ComPort Redirector Management: Internal web server, SNMP v1, SNMP v2, SNMP v3, Serial Login Telnet SSH login, XML ConsoleFlow Upgradeable FW via the Web Manager, FTP or serial port Internal Web Server: Customizable with CGI Web content on local file system and updatable through ftp Environmental: Operating: 0° to 55° C (32° to 131° F) Storage: -40° to 70° C (-40° to 151° F) Relative Humidity: 5 to 95%, noncondensing
Package Contents	EDS EDS3016PS Device Server Power Cord
Certifications & Standards	Regulatory Approvals: FCC IC CE UL/CB
Network & Communication
Network Standard	10/100/1000Base-T
Ethernet Technology	Gigabit Ethernet
Physical Characteristics
Weight (Approximate)	1.36 lb
Form Factor	Desktop
Form Factor	Wall Mountable
Height	2.4″
Width	8.9″
Depth	5″
Power Description
Input Voltage	120 V AC
Input Voltage	230 V AC
Plug/Connector Type	IEC Connector
